1585 MHz Cavity Notch Filter
1585 MHz Cavity Notch Filter
GENERAL CHARACTERISTICS
| Dimensions | 5.16 x 2.05 x 1.1 in. |
|---|---|
| Power Handling | 1 W CW Max |
| Connector Type | SMA (F) |
| High Side Passband Insertion Loss | 1.0 dB Max |
| Low Side Passband Insertion Loss | 1.0 dB Max |
| Notch Center Frequency | 1585 MHz |
| Passband Above Notch | 1627 - 5000 MHz |
| Passband Below Notch | 600 - 1518 MHz |
| Rejection in Bandwidth | 20 dB Min @ 1560 - 1610 MHz |
| Return Loss | 12 dB Min |
