2065 MHz Monoblock Ceramic Bandpass Filter on Evaluation Board
In stock
Model
AE2065CB1847-E
2065 MHz Monoblock Ceramic Bandpass Filter on Evaluation Board
Part number AE2065CB1847 on an Eval Board with SMA connectors
2065 MHz Monoblock Ceramic Bandpass Filter on Evaluation Board
Part number AE2065CB1847 on an Eval Board with SMA connectors
GENERAL CHARACTERISTICS
| Center Frequency | 2065 MHz |
|---|---|
| Power Handling | 5 W |
| Connector Type | SMA F |
| Band Width | 90 MHz Min |
| Insertion Loss | 1.0 dB Max |
| Pass Band | 2020 - 2110 MHz |
| Rejection (high side) | 60 dB Min @ 2200 MHz |
| Rejection (low side) | 60 dB Min @ 1900 MHz |
| Return Loss | 20 dB MIn |
