44-50 GHz Cavity Bandpass Filter
Out of stock
Model
AE47000B11572
44-50 GHz Cavity Bandpass Filter
44-50 GHz Cavity Bandpass Filter
GENERAL CHARACTERISTICS
| Center Frequency | 47 GHz |
|---|---|
| Dimensions | 1.57 x 0.629 x 0.314 inches |
| Power Handling | <5 W |
| Connector Type | 2.4mm (F) |
| Band Width | 6 GHz |
| Insertion Loss | <1.7dB |
| Pass Band | 44-50 GHz |
| Rejection (high side) | >45dB @ 55 GHz |
| Rejection (low side) | >45dB @ 37.5 GHz |
