5650-5675 MHZ / 5750-5850 MHz Cavity Diplexer
In stock
Model
AE5662-5800DB5573
5650-5675 MHz / 5750-5850 MHz Cavity Diplexer
5650-5675 MHz / 5750-5850 MHz Cavity Diplexer
GENERAL CHARACTERISTICS
| Dimensions | 6.0 x 1.50 x 0.69 in. |
|---|---|
| Return Loss | 15 dB Min |
| Power Handling | 35 W CW |
| Insertion loss (dB) | 1.5 dB Max |
| Band 2 | 5770 - 5850 MHz |
| Band 1 | 5650 - 5695 MHz |
| Band 2 Bandwidth | 80 MHz |
| Band 1 Bandwidth | 45 MHz |
